PC 3000 SSD

  • Overview
  • Technical Features
  • Video Tutorials

The PC-3000 SSD contains a set of specialized utilities for working with solid-state drives. This set includes the Universal Utility for diagnosing any SSD based on the ATA-8 specification (both currently existing models and those that will be manufactured in future) and the Active Utilities (Special Utilities) intended for working with a particular drive model in factory mode. It enables to deeply diagnose SSDs, to perform service operations, to re-write the drive's microcode, to get direct access to memory chips, to carry out low-level formatting blocking the damaged cells and placing their addresses into the defect table, and to perform many other useful operations.

The PC-3000 SAS is a hardware-software solution intended for testing and restoring damaged HDDs with SAS (Serial Attached SCSI) or SCSI based interfaces. The PC-3000 SAS coupled with the Data Extractor SAS forms the PC-3000 SAS/SCSI Professional System, which allows you to recover data from SAS or SCSI based HDDs. To repair these HDDs, you only need the PC-3000 SAS – for data recovery you need both the PC-3000 SAS and the Data Extractor SAS.

  • Form factor: Embedded PC expansion board which uses two adjacent slots
  • Interface type: Four-channel PCI Express 2.5 GB/s
  • Diagnostic ports (location): 4 - SAS (internal)
  • Maximum Data Transfer Speed: 300 MB/sec for each port
  • Processing modes:
  • SATA - UDMA133/100/66/33, PIO4/3/2/1/0
  • PATA - UDMA100/66/33, PIO4/3/2/1/0
  • Power adapter: four-channel adapter with overvoltage and current
  • overloading protection: HDD connectors are internal.
  • Supported HDD: from 18 GB to 2 TB; 3.5", 2.5"
  • OS Platforms: Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10; х86, х64

  • Recommended PC configuration:
  • CPU: Intel Core i5 (Quad Core)
  • RAM: 8GB
  • Storage configuration: 1 TB HDD
  • LCD Monitor: 22", 1920x1080

  • PC-3000 SSD has the following functions for data recovery:

    • verify and restore the SSD’s service information
    • read and write the content of the SSD’s ROM
    • load the microcode into the drives’s RAM
    • emulate the translator operation in order to get access to user data
    • view the password and reset the password that was earlier set on an SSD
    • turn off background processes in an SSD to prevent data damage
    • provide direct access to the content of memory chips (it makes unsoldering unnecessary)
    • work with the Data Extractor
